Product Specifications:
Thickness | Width |
0.03-0.15mm | 510-1500mm |
Product Color: Can be customized according to customer needs (minimum order quantity is 6 tons).
I. Product Introduction:
Our factory produces electrical polyester fiber nonwoven fabric (7031), which is made from polyester staple fiber (PET) using a thermal bonding method and mechanically carded into a web, resulting in oriented fiber distribution.
It features high heat resistance, excellent impregnation and dielectric properties, a uniform and smooth fabric surface, small thickness deviation, high tensile strength, and a neat appearance.
II. Specific Requirements:
1. Appearance:
The surface of the nonwoven fabric should be uniform and flat, neatly rolled, and free from damage and contamination. Neps and fiber bundles are permissible within the thickness tolerance range.
2. Dimensions:
(1) 7031 nonwoven fabric is supplied in rolls, each roll having a diameter of not less than 250mm, with no more than three sections per roll, the smallest section being not less than 100mm, and each section clearly marked. The inner diameter of the paper tube is 76mm.
(2) The maximum width of 7031 nonwoven fabric is 1560mm, with a permissible deviation of ±5mm.
(3) The thickness and permissible deviation of 7031 nonwoven fabric should conform to the provisions of Table 1.
(4) Other sizes and specifications of nonwoven fabric can be specified according to the contract.
(5) The physical and mechanical properties of the nonwoven fabric should conform to the relevant provisions of Table 1.
Table 1
Number | Performance | Unit | Required nominal thickness (mm) | 0.03 | 0.035 | 0.04 | 0.05 | 0.06 | 0.07 | 0.08 | 0.1 | 0.12 | 0.13 | 0.15 | |
1 | Quantitative | g/㎡ | 21 | 24 | 28 | 35 | 42 | 49 | 56 | 70 | 85 | 91 | 100 | ||
2 | Quantitative Inequality | ％ | ≤10 | ||||||||||||
3 | Apparent density | g/cm² | 0.65±0.10 0.70±0.10 | ||||||||||||
4 | Tensile strength | Vertical | N/50mm | ≥30 | ≥35 | ≥40 | ≥60 | ≥70 | ≥80 | ≥90 | ≥100 | ≥150 | ≥200 | ≥240 | |
Horizontal | Width | ≥6 | ≥8 | ≥10 | ≥20 | ≥22 | ≥25 | ≥27 | ≥30 | ≥50 | ≥70 | ≥100 | |||
5 | Elongation at break | Vertical | ％ | ≥6 | ≥6 | ≥6 | ≥6 | ≥6 | ≥8 | ≥8 | ≥10 | ≥10 | ≥10 | ≥10 | |
Horizontal | ％ | ≥3 | ≥3 | ≥3 | ≥3 | ≥3 | ≥5 | ≥5 | ≥5 | ≥5 | ≥8 | ≥8 | |||
6 | Thermal shrinkage rate | ％ | ≤4 ≤3 | ||||||||||||
Remark | Heat shrinkage test conditions：150℃，1 hour | ||||||||||||||
III. Physical and Mechanical Properties of 7031 Nonwoven Fabric
1. Packaging: Each roll of nonwoven fabric is wrapped in a plastic film, then an outer waterproof woven bag. The ends of the core are sealed with corresponding plastic cores. The inner tube is a 1.8cm thick high-pressure paper tube.
2. Marking: The outer packaging bag should be marked with the manufacturer, product name, model, specifications, batch number, net weight, production date, etc.
3. Storage: 7031 nonwoven fabric should be stored in a cool, dry, clean, and well-ventilated warehouse below 40℃. It should not be near fire sources or heating, and should not be exposed to direct sunlight. The shelf life is one year.
IV. Scope of application:
Widely used in composite materials (DMD, DM, DMDM), mica tape reinforcing materials, electrical laminates, insulating varnish cloth base fabric, and end wrapping of electrical appliances, transformers, and motor coils. It is also suitable for small and flexible cables, household electrical cables, communication optical cables, and can replace various types of paper insulation materials.
Polyester Fiber Nonwoven Fabric Material is a versatile, high-performance fabric widely used in industrial, medical, automotive, filtration, and consumer applications. Unlike woven or knitted textiles, nonwoven fabrics are made by directly bonding fibers through mechanical, thermal, or chemical processes, resulting in a lightweight, durable, and uniform material.
Understanding Polyester Fiber Nonwoven Fabric Material Price is essential for buyers, engineers, and purchasing managers who need to make cost-effective decisions while ensuring high-quality performance. Prices vary based on fabric weight, thickness, fiber type, production process, flame-retardant treatment, and supplier reliability.
This guide covers product overview, technical specifications, applications, usage instructions, and common questions, with insights into factors affecting pricing and cost-efficiency.
Polyester Fiber Nonwoven Fabric is primarily made from polyethylene terephthalate (PET) fibers, offering excellent mechanical strength, dimensional stability, thermal resistance, and chemical resistance.
Key characteristics include:
Lightweight and flexible, yet strong and durable
High tensile and tear strength
Thermal resistance for continuous use up to 150°C
Flame-retardant options available for safety-critical applications
Low moisture absorption for industrial and electrical use
Cost-effective and recyclable
The price of polyester fiber nonwoven fabric is influenced by material quality, production method, weight, thickness, and any additional treatments such as flame-retardancy or anti-static coating. Bulk orders or long-term contracts with manufacturers often reduce unit cost, while specialty nonwovens with advanced performance features may be priced higher.
Typical specifications of polyester fiber nonwoven fabric affecting performance and price include:
Material Composition: 100% PET fibers or blends with polypropylene or other synthetic fibers
Manufacturing Process: Spunbond, needle-punched, hydroentangled, or thermal bonded
Fabric Weight: 20 g/m² – 400 g/m²; heavier fabrics generally cost more
Thickness: 0.1 mm – 5 mm, adjustable based on application
Fiber Orientation: Random or directional for enhanced mechanical strength
Tensile Strength: Customizable, higher strength may increase price
Porosity: Adjustable for filtration or insulation purposes
Thermal Resistance: Continuous operation up to 150°C, price may vary with high-temperature-resistant variants
Flame Retardancy: Optional UL or EN compliant treatments may affect cost
Color: White, gray, or customizable; dyed fabrics may incur additional charges
Eco Compliance: RoHS and REACH compliant, recyclable material
Manufacturers often provide detailed datasheets specifying the weight, thickness, density, and treatment type, which are crucial for pricing transparency.
Several factors determine the final cost of polyester fiber nonwoven fabrics:
Fabric Weight and Thickness: Heavier and thicker fabrics use more raw materials, increasing the price per square meter or roll.
Fiber Quality: Premium PET fibers with uniform diameter and high tensile strength command higher prices.
Production Method: Spunbond and needle-punched processes differ in cost; hydroentangled fabrics may be more expensive due to additional processing.
Special Treatments: Flame retardant, anti-static, hydrophobic, or chemical-resistant coatings add to production costs.
Order Quantity: Bulk orders reduce per-unit cost, while small quantities or custom sizes increase it.
Supplier Reputation and Location: Established manufacturers with quality certifications may charge premium prices.
Customization: Color, fiber blend, layering, or lamination services influence cost.
Market Demand: Global polyester prices, raw material availability, and shipping costs affect market prices.
Understanding these factors helps buyers select a cost-effective yet high-quality polyester fiber nonwoven fabric for their projects.
Polyester fiber nonwoven fabrics are highly versatile, serving multiple industries:
Surgical gowns, masks, caps, and shoe covers
Disposable bed sheets and drapes
Sanitary napkins, diapers, and adult incontinence products
Cleaning wipes for healthcare use
Air, water, and oil filtration media
Geotextiles for soil stabilization and erosion control
Protective clothing for industrial workers
Insulation layers in machinery and electrical equipment
Interior linings, upholstery, and insulation
Noise and vibration dampening materials
Flame-retardant layers for battery packs and wiring
Cleaning wipes, dusters, and absorbent pads
Disposable tablecloths, aprons, and protective covers
Packaging and cushioning materials
Oil spill absorbents and filtration media
High-temperature or flame-retardant insulation
Hydrophobic or hydrophilic fabrics for liquid management
Pricing may vary depending on the application, as specialized treatments or higher fabric weights increase cost.
Proper handling ensures optimal performance and longevity:
Cutting and Shaping: Use sharp scissors, rotary cutters, or laser cutting tools. Avoid stretching to maintain fiber alignment and mechanical strength.
Layering and Lamination: Stack multiple layers for filtration, insulation, or protective purposes. Heat or adhesive lamination can enhance stability.
Cleaning: For reusable fabrics, follow manufacturer cleaning guidelines. Avoid harsh chemicals unless fabric is chemically treated.
Storage: Store rolls in a cool, dry, ventilated area, away from direct sunlight, humidity, and extreme temperatures. Proper storage preserves material quality.
Safety Precautions: Wear gloves when handling large rolls, and avoid inhaling fibers during cutting or processing.
Q1: How is the price of polyester fiber nonwoven fabric determined?
A1: Pricing depends on fabric weight, thickness, fiber quality, production method, treatments, order quantity, and supplier. Specialty or flame-retardant fabrics are typically higher in cost.
Q2: Can I get customized polyester fiber nonwoven fabrics?
A2: Yes. Manufacturers can tailor fiber type, thickness, weight, porosity, color, and treatments to suit specific applications.
Q3: Are these fabrics environmentally friendly?
A3: Many are recyclable and produced in compliance with RoHS and REACH standards, ensuring eco-friendly use.
Q4: Are nonwoven fabrics reusable?
A4: It depends. Medical and hygiene products are generally disposable, while industrial, filtration, or geotextile applications may allow reuse.
Q5: Do flame-retardant or high-temperature fabrics cost more?
A5: Yes. Special treatments like flame-retardant coatings or high-temperature-resistant fibers increase production costs and final price.
Q6: How can I reduce costs without compromising quality?
A6: Bulk orders, standardized sizes, and negotiating long-term supply agreements can lower unit costs while maintaining quality.
Q7: Can I compare prices between different manufacturers?
A7: Always compare quality, certifications, production capacity, customization options, and shipping costs, not just per-unit price.
Lightweight yet strong and durable
Excellent thermal, chemical, and mechanical properties
Flame-retardant and hydrophobic/hydrophilic options available
Low moisture absorption
Customizable thickness, weight, and fiber orientation
Versatile for medical, industrial, automotive, consumer, and environmental applications
Cost-effective and energy-efficient production
Recyclable and environmentally compliant
Understanding Polyester Fiber Nonwoven Fabric Material Price is crucial for buyers and industry professionals seeking cost-effective, high-performance solutions. Pricing depends on material quality, weight, thickness, production process, and special treatments. Polyester fiber nonwoven fabrics offer versatility, durability, flame retardancy, thermal resistance, and chemical stability, making them ideal for medical, industrial, automotive, and consumer applications. By selecting a reputable manufacturer and considering customization options, buyers can achieve both performance and cost efficiency while ensuring compliance with international standards.
